MLQ5-100A-1000A ATS controller dual power diesel generator part ac 3 phase Automatic Transfer Switch for Generator

MLQ5 isolated dual-power automatic transfer switch is an automatic the obvious visible state Realize safe isolation, greatly improve the transfer switch that integrates switch and logic control, does not need electrical performance and mechanical performance.
an extermal controller, and truly realizes mechatronics. Ithas functions The overal design of the MLQ5 switch is a marble shape, small and such as voltage detection, frequency detection, communication sturdy. It has strong dielectric properties, protection ability and reliable interface, electrical and mechanical interlocking, etc., can realize operation safety.
automatic, electric remote, emergency manual control.
The switch is suitable for the automatic conversion between the main The operation is realized by the logic control board using various power supply and the backup power supply of the power supply system logic commands to manage the operation and operation of the motor or the automatic conversion and safety isolation of two load devices.
and gearbox. The motor drives the switch spring to store energy, and The switch has beautifulappearance, novetly, simplicity, smallsize and the aceleration mechanism is releasedinstantaneously to quicky ulfinctons, makingitanidealchoiceforaifierentocasions.
connect and break the circuit or perform circuit conversion. Through the obvious visible state Realize safe isolation, greatly improve the electrical performance and mechanical performance.
The overall design of the MLQ5 switch is a marble shape, small and sturdy. It has strong dielectric properties, protection ability and reliable operation safety.
The switch is suitable for the automatic conversion between the main power supply and the backup power supply of the power supply system or the automatic conversion and safety isolation of two load devices. The switch has beautiful appearance, novelty, simplicity, small size and fullfunctions, making it an ideal choice for different occasions.

Standards compliant
MLQ5 series automatic transfer switches comply with the series standards: IEC60947-1(1998)/GB/T4048.1"General Rules for Low-Voltage Switchgear and Control Equipment"
IEC60947-3(1999)/GB14048.3"Low-voltage switchgear and control equipment, low-voltage switches, isolators, isolating switches and fuse combinations"
IEC60947-6(1999)/GB14048.11"Low-voltage switchgear and control equipment multifunctional electrical appliances Part 1: Automatic transfer switch electrical appliances"
